Designed for handling water in water supply systems of industrial projects and public utilities. Used also for agricultural land irrigation and drainage.
Electrically driven horizontal end-suction single-stage volute casing centrifugal pumps with overhung impeller and bearing bracket. KSh series pumps have an optimized-NPSH impeller design with blades extending well into the suction chamber. The rotor is carried by grease-lubricated or oil-ring lubricated (in case of KSH series pumps) antifriction bearings. Shaft sealing: packed gland.
Additional and technical information
Nos | Pump make | Capacity, m3/h | Head, m | Rotational speed (synchr.), rpm | Motor nominal power, kW |
1 | K 125-315 | 200 | 32 | 1500 | 30 |
2 | K 125-315а | 200 | 26 | 1500 | 30 |
3 | K 125-315б | 200 | 21 | 1500 | 22 |
4 | K 125-315д | 200 | 35.5 | 1500 | 37 |
5 | КШ 100-250 | 200 | 80 | 3000 | 75 |
6 | КШ 100-250а | 200 | 71 | 3000 | 75 |
7 | КШ 100-250б | 200 | 56 | 3000 | 55 |
8 | КШ 100-250д | 200 | 90 | 3000 | 90 |
9 | КШ 100-315 | 200 | 125 | 3000 | 132 |
10 | КШ 100-315а | 200 | 105 | 3000 | 110 |
11 | КШ 100-315д | 250 | 125 | 3000 | 132 |
12 | КШ 125-200 | 315 | 50 | 3000 | 75 |
13 | КШ 125-200а | 315 | 42 | 3000 | 55 |
14 | КШ 125-200б | 315 | 31.5 | 3000 | 45 |
15 | КШ 125-250 | 315 | 80 | 3000 | 110 |
16 | КШ 125-250а | 315 | 71 | 3000 | 90 |
17 | КШ 125-250б | 315 | 60 | 3000 | 75 |
