NMV Series In-Line Vertical Multistage Can
Designed for transporting crude oil through long-distance pipelines and end products (diesel fuel, motor petrol, jet engine fuel) through product pipelines.
Vertically suspended, in-line, can, end-suction multistage diffuser centrifugal pumps with the first stage double flow impeller, provided with inducers. Driven by induction motors by means of a spacer-type diaphragm flexible coupling. The pump rotor is carried by the top thrust and radial antifriction bearing and the bottom medium lubricated hydrodynamic plain bearing. Shaft sealing: by mechanical seal. Designed in compliance with API Standard 610 requirements.
| Nos | Pump make | Capacity, m3/h | Head, m | Rotational speed, rpm |
|---|---|---|---|---|
| 1 | NMV 200-75 | 200 | 75 | 1500 |
| 2 | NMV 200-100 | 200 | 100 | 1500 |
| 3 | NMV 200-125 | 200 | 125 | 1500 |
| 4 | NMV 200-150 | 200 | 150 | 1500 |
| 5 | NMV 200-175 | 200 | 175 | 1500 |
| 6 | NMV 200-200 | 200 | 200 | 1500 |
| 7 | NMV 200-225 | 200 | 225 | 1500 |
| 8 | NMV 200-250 | 200 | 250 | 1500 |
| 9 | NMV 200-275 | 200 | 275 | 1500 |
| 10 | NMV 200-300 | 200 | 300 | 1500 |
| 11 | NMV 315-90 | 315 | 90 | 1500 |
| 12 | NMV 315-120 | 315 | 120 | 1500 |
| 13 | NMV 315-150 | 315 | 150 | 1500 |
| 14 | NMV 315-180 | 315 | 180 | 1500 |
| 15 | NMV 315-210 | 315 | 210 | 1500 |
| 16 | NMV 315-240 | 315 | 240 | 1500 |
| 17 | NMV 315-270 | 315 | 270 | 1500 |
| 18 | NMV 315-300 | 315 | 300 | 1500 |
| 19 | NMV 500-105 | 500 | 105 | 1500 |
| 20 | NMV 500-140 | 500 | 140 | 1500 |
| 21 | NMV 500-175 | 500 | 175 | 1500 |
| 22 | NMV 500-210 | 500 | 210 | 1500 |
| 23 | NMV 500-245 | 500 | 245 | 1500 |
| 24 | NMV 500-280 | 500 | 280 | 1500 |
| 25 | NMV 500-315 | 500 | 315 | 1500 |
| 26 | NMV 800-120 | 800 | 120 | 1500 |
| 27 | NMV 800-160 | 800 | 160 | 1500 |
| 28 | NMV 800-200 | 800 | 200 | 1500 |
| 29 | NMV 800-240 | 800 | 240 | 1500 |
| 30 | NMV 800-280 | 800 | 280 | 1500 |
| 31 | NMV 800-320 | 800 | 320 | 1500 |
| 32 | NMV 1250-110 | 1250 | 110 | 1500 |
| 33 | NMV 1250-165 | 1250 | 165 | 1500 |
| 34 | NMV 1250-220 | 1250 | 220 | 1500 |
| 35 | NMV 1250-275 | 1250 | 275 | 1500 |
| 36 | NMV 1250-330 | 1250 | 330 | 1500 |
| 37 | NMV 1800-110 | 1800 | 110 | 1500 |
| 38 | NMV 1800-165 | 1800 | 165 | 1500 |
| 39 | NMV 1800-220 | 1800 | 220 | 1500 |
| 40 | NMV 1800-275 | 1800 | 275 | 1500 |
