НПВ, НПВ-М Series Vertical Can, Diffuser

Home › Pumping equipment › НПВ, НПВ-М Series Vertical Can, Diffuser

Designed for delivering crude oil or oil products to the main pipeline pumps to ensure their satisfactory suction performance (cavitation-free operation). Suitable also as mixing pumps to transfer oil in tank farms and as loading pumps to fill end products into tank wagons at the oil refineries.

Electrically driven vertically suspended, end-suction single- or multistage (according to the required head) diffuser centrifugal pumps equipped with an inducer. The major pump components are a can (outer casing) and a withdrawable rotating assembly with a motor stool. Upgraded versions (identified with “M”) feature a barrel-shaped delivery casing. The pump rotor is carried by the top thrust and radial bearing (comprising two ball bearings) and the bottom medium lubricated plain bearing. Shaft sealing: by mechanical seal.

Additional and technical information

Nos	Pump make	Capacity, m³/h	Head, m	Rotational speed (synchr.), rpm	Motor nominal power, kW
1	НПВ 150-60	150	60	3000	90
2	НПВ 150-60	150	90	3000	90
3	НПВ 300-60-С	300	40	3000	90
4	НПВ 300-60	300	60	3000	90
5	НПВ 300-60	300	150	3000	200
6	НПВ 600-60	600	60	1500	200
7	НПВ 1250-30-М	1250	30	1000	160
8	НПВ 1250-60-М	1250	60	1000	315
9	НПВ 1250-110-М	1250	110	1000	630
10	НПВ 2500-40-М	2500	40	1000	400
11	НПВ 2500-80-М	2500	80	1000	800
12	НПВ 2500-120-М	2400	103	1000	800
13	НПВ 2500-120-М	2500	120	1000	1250
14	НПВ 2500-120а-М	2500	110	1000	1000
15	НПВ 3600-45-М	3600	45	1000	630
16	НПВ 3600-90-М	3600	90	1000	1250
17	НПВ 3600-90-М	4500	80	1000	1600
18	НПВ 3600-120-М	3600	120	1000	1600
19	НПВ 3600-135-М	3600	135	1000	2000
20	НПВ 3600-135а-М	3600	120	1000	1600
21	НПВ 5000-60-М	5000	60	1000	1250
22	НПВ 5000-120-М	5000	120	1000	2000
23	НПВ 5000-120-М1	5000	120	1000	2000
24	НПВ 5000-120-М2	5000	120	1000	2000
